Gert Drapers wrote a great detailed post on how to Create T-SQL Static Code Analysis Rules as one of the new features in the GDR release is that you can create your own T-SQL Static Code Analysis rules.

The post will guide you through creating your first rule.

The VSTS Virtual Machines are all updates with fresh bits and expiration dates and now available in 4 different flavors on Microsoft Download Center thanks to Brian Randell

The new Virtual Machines are a VSTS “all-up” image with Team Foundation Server, Team Build, Team Explorer and Team Suite with the latest SP1 installed, and a TFS “only” image with just Team Foundation Server, Team Build and Team Explorer with the latest SP1 installed. But they are produced as Virtual PC 2007/Virtual Server 2005 R2 Compatible images and Hyper-V Compatible images to suite everybody’s needs …

The images are updated with the following:

• The latest Virtual Machine additions or Integration Services Components.
• All of the latest Windows Updates as of December 1, 2008.
• Team Foundation Server 2008 SP1
• Visual Studio 2008 Team Suite SP1
• Team System Web Access 2008 SP1
• Team Foundation Power Tools, October 2008 Update.
• The latest MSSCCI Provider.
• Team Explorer 2005 (this allows you to work with TFS from Visual Studio 2005 which is installed so that you can edit and customize TFS reports)
• The GDR for the product formally known as Visual Studio 2008 Database Edition (aka Data Dude).
• Current Process Explorer, Process Monitor, and Background Info.

All can be downloaded as follows:

• VSTS “all-up” Virtual PC/Virtual Server image (6 GB download, expands to 15 GB)
• TFS “only” Virtual PC/Virtual Server image (3 GB download, expands to 8 GB)
• VSTS “all-up” Hyper-V image (6 GB download, expands to 15 GB)
• TFS “only” Hyper-V image (3 GB download, expands to 8 GB)

Enjoy :)

Visual Studio Team System 2008 Database Team just released 6 additional languages of the recently released GDR on Microsoft Download Center as follows:

Chinese (Traditional, Taiwan)

• http://download.microsoft.com/download/1/9/D/19D1CB8C-82A8-4736-AFF4-51F2E343A312/Readme.mht
• http://download.microsoft.com/download/1/9/D/19D1CB8C-82A8-4736-AFF4-51F2E343A312/setup.exe

German

• http://download.microsoft.com/download/6/E/F/6EFD0F85-C8C3-4B47-9426-22B0ED4D12CE/Readme.mht
• http://download.microsoft.com/download/6/E/F/6EFD0F85-C8C3-4B47-9426-22B0ED4D12CE/setup.exe

Spanish

• http://download.microsoft.com/download/A/1/0/A10A906C-5CB9-4DAE-9CC2-B4B233B8AD6B/Readme.mht
• http://download.microsoft.com/download/A/1/0/A10A906C-5CB9-4DAE-9CC2-B4B233B8AD6B/setup.exe

Italian

• http://download.microsoft.com/download/6/3/1/6313DB42-DBC5-499F-AB3E-2119689A6A3E/Readme.mht
• http://download.microsoft.com/download/6/3/1/6313DB42-DBC5-499F-AB3E-2119689A6A3E/setup.exe

Japanese

• http://download.microsoft.com/download/3/D/1/3D14DB8E-4507-4AC3-BE96-DDD5E1FF1C8B/Readme.mht
• http://download.microsoft.com/download/3/D/1/3D14DB8E-4507-4AC3-BE96-DDD5E1FF1C8B/setup.exe

Korean

• http://download.microsoft.com/download/0/C/2/0C2CAB8A-08D4-4354-9883-502C2639DB04/Readme.mht
• http://download.microsoft.com/download/0/C/2/0C2CAB8A-08D4-4354-9883-502C2639DB04/setup.exe

Patrick Sirr posted a detailed post about the latest VSTS Database Edition GDR Import Scripts Add-In that is amazing.

In this blog I’ll introduce you to the Import Scripts add-in to the General Distribution Release (GDR) for Visual Studio Team System 2008 Database Edition. With this add-in Visual Studio can import multiple scripts to populate a target database project. I’ve included the source code but, in order to compile the install project you’ll need to install Votive 3.0 (I used 3.0.4707.0).

Mike Fourie had a few minor updates on the handy reference to aid your work with building software in TFS 2008.

System Center 2008 Management Packs for TFS 2008 is now available for download on Microsoft Download Center

The Team Foundation Server (TFS) 2008 Management Pack monitors exposed services of TFS. This management pack includes event rules and monitors. It is designed to proactively monitor quality and availability of TFS services and even automate recovery in some scenarios.

Feature Summary

• Auto discovery of TFS components
• Leverages ASP.NET MP and SQL MP
• Implements containment hierarchy reflecting logical architecture of the Product
• Implements a proper health model using Monitors
• Contains tasks, diagnostic and recovery for certain failures
• Events indicating service outages
• Alerts indicating configuration issues and connected data source changes
• Verification that all dependant services are running
• Targeted running of BPA against TFS Servers from Operator Console

I recently blogged about VSTS 2008 Database Edition GDR RC1 which is now finally a RTW available for download from Microsoft Download Center :)

Thanks to Mike Fourie for the great handy reference that will aid working with Team Builds on TFS 2008

Some of Team System MVPs started working on creating some translations for Team System Web Access through CodePlex as the TSWA Community Translation Project

The great work resulted in 7 new languages that are now available through CodePlex as follows:

• Croatian
• Portuguese (Brazilian)
• Turkish
• Danish
• Swedish
• Polish
• Dutch

Another release is currently in progress that will contain:

• Norwegian
• Arabic
• Portugese

Cameron Skinner wrote an amazing post discussing the composition of VSTS 2010, giving some higher level descriptions of the parts that make up the whole product.

It's a must read post ... Well done Skinner ...

Team Foundation Server Collaboration Providers is a new CodePlex Project that targets Community Contribution for Collaboration providers for different IM and VoIP integration as the TFS 2008 Power Tools enables rich integration with other team members via IM and VoIP chat.

The Power Tools integrates with Live Communicator and Windows Live Messenger Out of the Box.

Skype Provider Initial version is now available as the first Collaboration Provider in the project with more to come ...

Never thought of listing all TFS 2008 Web Services before until I needed to start access them directly.

Below is the full list of Web Services which comes in two versions, V1.0 and V2.0 for backward compatibility I believe ...

Build Service

V1.0

• http://YourTFSServerName:8080/Build/V1.0/BuildController.asmx
• http://YourTFSServerName:8080/Build/V1.0/BuildStore.asmx
• http://YourTFSServerName:8080/Build/V1.0/Integration.asmx
• http://YourTFSServerName:8080/Build/V1.0/PublishTestResultsBuildService.asmx
• http://YourTFSServerName:8080/Build/V1.0/PublishTestResultsBuildService2.asmx

V2.0

• http://YourTFSServerName:8080/Build/V2.0/BuildService.asmx
• http://YourTFSServerName:8080/Build/V2.0/Integration.asmx

Services Service

V1.0

• http://YourTFSServerName:8080/Services/v1.0/AuthorizationService.asmx
• http://YourTFSServerName:8080/Services/v1.0/CommonStructureService.asmx
• http://YourTFSServerName:8080/Services/v1.0/EventService.asmx
• http://YourTFSServerName:8080/Services/v1.0/GroupSecurityService.asmx
• http://YourTFSServerName:8080/Services/v1.0/ProcessTemplate.asmx
• http://YourTFSServerName:8080/Services/v1.0/projectMaintenance.asmx
• http://YourTFSServerName:8080/Services/v1.0/Registration.asmx
• http://YourTFSServerName:8080/Services/v1.0/ServerStatus.asmx

V2.0

• http://YourTFSServerName:8080/Services/v2.0/GroupSecurityService2.asmx

Version Control Service

V1.0

• http://YourTFSServerName:8080/VersionControl/v1.0/Administration.asmx
• http://YourTFSServerName:8080/VersionControl/v1.0/Integration.asmx
• http://YourTFSServerName:8080/VersionControl/v1.0/ProxyStatistics.asmx
• http://YourTFSServerName:8080/VersionControl/v1.0/Repository.asmx

Warehouse Service

V1.0

• http://YourTFSServerName:8080/Warehouse/v1.0/warehousecontroller.asmx

WorkItem Tracking Service

V1.0

• http://YourTFSServerName:8080/WorkItemTracking/v1.0/ClientService.asmx
• http://YourTFSServerName:8080/WorkItemTracking/v1.0/ConfigurationSettingsService.asmx
• http://YourTFSServerName:8080/WorkItemTracking/v1.0/ExternalServices.asmx
• http://YourTFSServerName:8080/WorkItemTracking/v1.0/Integration.asmx
• http://YourTFSServerName:8080/WorkItemTracking/v1.0/SyncEventsListener.asmx

Sticky Buddy is a Digital Dashboard that will run off Team Foundation Server and allow teams to display information on the status of their development on one or many projects.

The application will consist of a main screen that queries a TFS Server and pulls a list of projects that the user can select for display and within each project it will display the iteration tree.

This tree will be displayed as a set of concentric columns that are populated with "Change Requests" and "Requirements" that are currently within that iteration path.

Each of the Work Items displayed will show limited information about itself, which user it is assigned to, its Area and title. But it will also display the number of sub items within each item. This will give an indication of the length of time necessary to complete all of the sub-work items within that iteration so it can be moved on to the next.

A set of rules will determine the color or icons associated with each item based on their status. These rules may include:

• Is this item overdue?
• Does this work item have any blocked work items associated with it?
• Does this work item have any risks associated with it?

Sticky Buddy is available on CodePlex

VSTS 2010 PDC Lab Session is available on Channel 9 that was done by Cameron Skinner

In the spirit of an agile sprint, see how to use the next version of Visual Studio Team System to manage user stories and re-factor existing architecture. Learn how to diagnose real production problems, debug in-production virtual labs, capture test data to eliminate the no-repro bugs, transparently plan, monitor, and adapt software projects.

The TFS Power Tools October 2008 Release is now available for download on Microsoft Download Center

New in the October Release

Team Members (NEW!)

• Adds a new node under each Team Project to the Team Explorer called "Team Members" that identifies people who work on the project.
• Serves as a "pivot point" for information about and operations on people and teams.

Windows Shell Extension (NEW!)

• Allows core version control operations within Windows Explorer without using Team Explorer.

PowerShell Support (NEW!)

• Provides a PowerShell pipeline and cmdlets for TFS. Initial support is for basic version control operations.

TFPT (Updated)

• tfpt searchcs - the Search Changesets Power Tool brings up a dialog from which the user can search for changesets that match specific combination of criteria including server path, committed date range, committed user, check-in comments and check-in notes.
• tfpt unshelve /undo - finds all pending changes in your workspace that match the changes in the shelveset and undoes them (including deleting the local files for pending adds).
